Honeywell RP4f Series Mobile Printer.

Honeywell RP4f Series Mobile Printer

Honeywell RP4f Series Mobile Printer Features

This portable printer provides big productivity gains and reduces errors by enabling workers to print labels at the location they need, so labels can be applied when and where they need to be applied. The RPf printer comes with powerful CPU and smart power management – allowing smooth, continuous operation so your workers can work efficiently with less media reloading, battery swaps, and downtime.

The RPf Series printer prints 25.4mm (1 in) to 104.1 mm (4.1 in) labels/receipts and can accommodate a wide variety of media, including the heavy stock necessary for hang tags and specialty label needs. Plus, its fast and easy-loading design means fewer interruptions and increased productivity in your application, whether using one type of media or several. The RPf Series has the latest 802.11 a/b/g/n/ac Wi-Fi capabilities for the best range and fast data communications on your WLAN. It also includes a Bluetooth 5.0 LE radio at no additional charge for when workers are outside of WLAN range or using the printer with a Bluetooth mobile computer.

Built on Honeywell’s software platform, the RPf printer offers IT managers easy integrated device management, a high level of security throughout the entire printer lifespan, and upgrades that allow your printers to be updated with enhanced features.

Honeywell RP4f Series Mobile Printer Specifications

FEATURES

  • Features
  • Rugged and reliable
  • Smart printing
  • High power efficiency
  • Application
  • Retail
  • Healthcare
  • T&L
  • Compatible Drivers
  • CUPS Driver for Linux
  • Certified Device Types for SAP
  • InterDriver Windows
  • Compatible Software
  • Operational Intelligence
  • Teklynx Labelview
  • BarTender
  • Nicelablel
  • SOTI

DIMENSIONS

  • Weight
  • 1.02 kg (2.24 lb) with battery, no media
  • Overall Dimensions
  • H x W x D: 187 mm x 164 mm x 77 mm (7.36 in x 6.46 in x 3.0 in)

PRINTING SPECIFICATIONS

  • Print Speeds
  • 25-125 mm/s (1-5 ips)
  • 2D Barcodes
  • All major 2D barcodes
  • Resolutions
  • 203 dpi
  • Downloadable Font Type
  • TrueType Font
  • Bitmap Font
  • OpenType Font (TrueType based)
  • Linear Barcodes
  • All major 1D barcodes

MEDIA

  • Printer Media Type
  • Linered
  • Tag
  • Linerless
  • Receipt
  • Label

NETWORK

  • Wireless Communication
  • NFC for pairing
  • IEEE 802.11 a/b/g/n/ac
  • OPEN, WEP, WPA/WPA2/WPA3 (Personal and Enterprise)

SOFTWARE & FIRMWARE

  • Printer Command Language
  • Direct Protocol (DP)
  • EZ-Print
  • CPCL
  • XML-enabled for SAP AII and Oracle WMS
  • Fingerprint (FP)
  • PDF
  • Intermec Printer Language (IPL)
  • C# Smart Printing
  • DPL
  • ZSim2 (ZPL-II)

MEMORY & DATA

  • Image File Format
  • GIF
  • PNG
  • PCX
  • BMP

HARDWARE

  • Printer Connection Interface
  • USB 2.0

ELECTRICAL

  • Battery Capacity Options
  • 4900 mAh

ENVIRONMENTAL

  • Storage Temperature
  • -30°C to 65°C (-22°F to 149°F)
  • Operating Humidity
  • 20 – 80 % non-condensing
  • Operating Temperature
  • -20°C to 55°C (-4°F to 131°F)

STANDARDS & APPROVALS

  • Protection Ratings
  • IP54
  • Drop Specifications
  • 2 m (6.6 ft)

SERVICE TERMS

  • Warranty Duration
  • One year factory warranty

OTHERS

  • Font Engine
  • Language support
  • Monotype Font Engine
  • WTLE for global
  • Storage Humidity
  • 20 – 80 % non-condensing
  • Print Method
  • Direct Thermal
  • Maximum Media Roll Diameter
  • 58 mm (2.25 in)
  • Tumble Specifications
  • 1,000 cycles at 0.5 m (1.6 ft)
  • Bluetooth Specifications
  • Bluetooth 5.1 + LE dual radio mode
