Intermec PB50 Mobile Label Printer.

Intermec PB50 Mobile Label Printer

Intermec PB50 Mobile Label Printer Features

  • Complements Intermec’s high speed, mobile, warehouse solutions
  • High-speed electronics and high-voltage battery deliver ultra-fast print speeds
  • Patented power management maximizes battery life
  • Communication options include WLAN, Bluetooth, serial and USB
  • Highest level wireless security in its class
  • Ample on-board memory keeps fonts resident on printer
  • Accepts multiple media types and widths
  • Designed for durability and ease of use
  • Remote management capability via Intermec SmartSystems™

Product Overview
The PB50 four-inch mobile label printer is the perfect complement to Intermec’s mobile computers, scanners and media to put your mobile workers in the warehouse fast lane. With the convenience of printing labels, tags and receipts where and when you need to through Bluetooth® and WLAN connectivity, the PB50 increases productivity for warehouse operations, or wherever you need a combination of wireless communication, ultra-fast print speeds and well-managed battery life in a rugged, wearable design.

Convenience of Bluetooth
The PB50 printer interfaces seamlessly with Bluetooth-enabled Intermec mobile computers including the CK31, CK61, and CV30 vehicle mount computer, along with the CN3, and 700 series. The PB50 offers the flexibility to either be worn using a shoulder strap or belt clip, or it can be mounted to a mobile cart or fork truck.

Unique Design
A unique design that combines a high-voltage battery, patented techniques for power management of the print head, and high speed electronics normally only used in desktop printers enable the PB50 to print the full-width of all pixels simultaneously and achieve “time to first label” in less than half the time of other label printers.*
Patented power management of the 32.6 watt hours of available power mean the PB50 will not only maintain consistent power to the print head to maintain high quality printing, but also prevent frequent disruptions for battery changes.

Latest Wireless Security
With the latest in wireless security including WEP (64 and 128), WPA/WPA2 Personal Mode, and WPA/WPA2 Enterprise Mode (PEAP, TTLS, LEAP-Open only), the PB50 is fully compatible with your wireless infrastructure, mobile computing and network security, so users won’t have to sacrifice peace of mind for the convenience of wireless operation.
The PB50 is supported by Intermec SmartSystems™ technology, delivering unique remote management capability. This allows managers to view details such as CPU part and serial number, battery voltages, and firmware versions. The user can also remotely update PB50 firmware via the host device.

In addition to accommodating a variety of media types, the unique design of the PB50 allows users to print labels, from 2” to 4” wide, which is valuable to companies needing a flexible solution to address multiple applications with a single device.

With 64MB of on board Flash memory and the ability to store a full Unicode font, the PB50 gives users the flexibility to print multiple languages on a single label. In addition, users can improve label throughput by storing frequently used label formats and graphics on the printer, eliminating the need to access files from the host system.

Easy to Use
The PB50 is also designed for ease of use making loading, charging, printing and diagnostics fast and simple. With straightforward, intuitive status indicators and audio feedback, end-users can be sure that the device has enough media, battery life, and wireless connectivity so they can perform their job efficiently.

Intermec PB50 Mobile Label Printer Specifications

Environment
Operating temperature: -15°C to 50°C (5°F to 122°F) with Bluetooth;
0°C to 50°C (32°F to 122°F) with 802.11g
Storage temperature: -22°C to 70°C (-30°F to 158°F)
Charging temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10 to 90% (non-condensing)
Electrostatic Discharge:
• Contact Discharge: +/-8kV
• Air Discharge: +/-10kV
Sealing: IP54, excluding media path
Drop spec: Survives 1.5m (5 ft.) drops to concrete

Physical Characteristics
Width: 160.02 mm (6.3 in)
Height: 174.5 mm (6.87 in)
Depth: 78.8 mm (3.10 in)
Weight: 976 g (34.4 oz) printer only
1190 g (42.0 oz) with battery
1495 g (52.7 oz) with battery and label roll

Power
Battery: Rechargeable 14.8V Li-Ion, 2200mAh (4 cells); 32.56 watt hours
Battery will retain 50% or more of original capacity after 500 charge/discharge cycles. Battery must be ordered separately.
Recharging: 4 hours maximum
Endurance per fully charged battery:
• Printing: Up to 1000 4” x 6” labels
• Standby mode: Up to 7 days for both
Bluetooth and 802.11 models
• On with active radio: 48 hours for Bluetooth; 24 hours for 802.11
AC Adapter: 50 watts
Voltage Range: 12V +/- 5%

Print Specifications
Print Speed and Resolution:
4 ips (100 mm/s)
203 dpi (8 dots/mm)
Print Technology
Print head: Direct thermal
Maximum print width: 108 mm (4.25 in)
