Handheld APAC Nautiz eTicket Pro.

Handheld APAC Nautiz eTicket Pro

This product has been retired. Please contact sales to discuss replacement products.

Handheld APAC Nautiz eTicket Pro Features

The Nautiz eTicket Pro® is a versatile PDA designed for payment transactions and validations. With its category-leading combination of performance features in a small but rugged package the Nautiz eTicket Pro is the perfect handheld for fare collection in public transport. The Nautiz eTicket Pro is designed to provide everything you need for optimum in-the-field computing performance – this handheld offers a total package of unmatched capabilities in a rugged format.

First of all, the Nautiz eTicket Pro is fast and powerful. Its high-speed 806 MHz Xscale processor, 256 MB RAM and 512 MB Flash memory is unsurpassed in the handheld market – this mobile computer can keep up with you. And it’s easy to use and practical. With Windows Mobile 6.1, a full VGA, daylight visible screen, and a battery that lasts more than a full workday on a single charge this handheld takes desktop computing efficiency out into the field.

The built-in smart card reader supports various ISO14443 type A/B RFID devices. The contactless electronic link between the card and the reader allows for the fast interface that is needed in security and payment systems.

The Nautiz eTicket Pro is also a feature-rich device. It has an integrated 3 megapixel autofocus camera, and it also includes integrated 2-D imager.

It offers GSM/UMTS voice and high speed HSDPA data connectivity with lightning-fast, 3G communication. The Nautiz eTicket has integrated Bluetooth and 802.11b/g, with WPA2 encryption for improved security and CCX certification for better interoperability. And with state-of-the-art SiRF Instant Fix II technology, the Nautiz eTicket’s GPS computes positions in seconds.

Finally, this handheld is tough and mobile enough to take anywhere. An IP65 rating means the Nautiz eTicket Pro is impervious to dust and highly water-resistant, and it can withstand drops from 1.8 meters and operate in a wide range of temperatures. It weighs only 410 grams and fits comfortably in your hand.

The Nautiz eTicket Pro brings together the latest features and technology to deliver a mobile handheld device that does it all, and does it well.

Handheld APAC Nautiz eTicket Pro Specifications

Size

160mm (6.3”) x 80 mm (3.15”) x 35.5mm (1.4”)

Weight

410 g (14.46 ounces) including rechargeable battery

Environment

Operating: -20 °C to 55 °C (-4 °F to 131 °F), MIL-STD-810G,

Method 501.4 Procedure II, MIL-STD 810G,

Method 502.4, Procedure I, II, III

Storage: -25 °C to 70 °C (-13 °F to 158 °F), MIL-STD-810G,

Method 501.4 Procedure II, MIL-STD 810G,

Method 502.4, Procedure I, II, III

Drop: 1.8 m (6 ft), 26 drops from 1.8 m, MIL-STD-810G,

Method 516.5, Procedure IV

Vibrations: MIL-STD-810G, Method 514.5 Procedures I & II

Sand & Dust: IP65, MIL-STD 810G

Water: IP65, MIL-STD 810G

Humidity: MIL-STD-810G, Method 507.4, 95% RH temp

cycle 0 °C/70 °C

Altitude: 4572 m (15.000 ft) at 5 °C (73 °F)

Processor/memory

Processor: Marvell PXA320 Xscale 806 MHz

Memory: 256 MB RAM

Data Storage

512 MB Flash

Operating System

Windows Mobile 6.1

Screen

3.5” VGA TFT LCD, 480 x 640 pixels,

daylight viewable

Keyboard

Numeric keypad

Battery

4400 mAh, all day operation with default settings,

rechargeable Li-ion

Connections

USB host/client

Serial (TTL)

Audio jack

IrDA

Ethernet (via optional desktop cradle accessory)

MicroSD slot

Smart Card Standards

RF Transmit Frequency: 13.56MHz

RF read/write range up to 5cm depending on tag

Standards Supported: ISO14443A, ISO14443B,

ISO18092

Smart Card Capacity

Connector: 2 internal SAM sockets and 1 SAM

socket behind the battery

Supported Tag-Ics

MIFARE® Standard 1kB, MIFARE® 4k, MIFARE®

Ultralight, MIFARE® PLUS, MIFARE® DESFIRE,

MIFARE® DESFIRE EV1, MIFARE® SmartMX, NFC,

ISO14443A tags, ISO14443B tags,

Felica RCS-860, Felica RCS-885

Communication

PAN: Bluetooth 2.0 + EDR

WLAN: integrated 802.11b/g, WITH WEP, WPA,

WPA2, CCX Cisco Compatible extensions

Integrated GPS SiRF III with Instant Fix II

GSM/UMTS (HSDPA/EDGE)

Integrated speaker & microphone

Camera Integrated 3 megapixel camera with autofocus

and LED Flash

Barcode Scanner

Integrated

2D Imager

Options

• Desktop cradle-, as standard

• Vehicle mount

• 12V Vehicle charger

• Carry cases
